The Mitsubishi FR-E540-2.2K-CH is a power inverter or variable frequency drive (VFD) manufactured by Mitsubishi Electric. It is designed to control the speed and torque of three-phase induction motors. Here are some specifications of the FR-E540-2.2K-CH:

- Power Rating: 2.2kW (3 HP)

- Input Voltage: Three-phase, 200-240VAC

- Output Voltage: Three-phase, 0 to Input Voltage

- Control Method: V/f (Voltage-frequency) control

- Frequency Range: 0.2 to 400Hz

- Overload Capacity: 150% of rated current for 60 seconds

- Cooling Method: Built-in fan for cooling

- Communication: RS-485 communication interface (built-in)

- Protection Features: Overcurrent, overvoltage, undervoltage, overload, and overheating protection

The FR-E540-2.2K-CH provides reliable and efficient motor control for various applications, including pumps, fans, conveyors, and other industrial machinery. It offers advanced features and settings for optimal motor performance and energy savings.
